Pipe Stanchions
Pipe Saddle Support – Fig. 420
Material: Carbon steel (304 and 316 stainless steel).
Finish: Plain, electro-galvanized or painted.
Service: Designed to be used in conjunction with a base stand to sup- port pipe...
Approvals: Complies with Federal Specification WW-H-171-E (Type# 37), A-A-1192 A...
Ordering: Specify size, figure number and finish. Base stand ordered separately...
Notes: There are no notes for this product.
Adjustable Pipe Saddle Support with Threaded Coupling – Fig. 421
Material: Carbon steel (304 and 316 stainless steel).
Finish: Plain, electro-galvanized or painted.
Service: Designed to be used in conjunction with a base stand to sup- port pipe...
Approvals: There are no approval options for this product.
Ordering: Specify pipe size, figure number and finish. Base stand can be ordered...
Notes: There are no notes for this product.
Adjustable Pipe Support – Fig. 422
Material: Carbon steel (304 and 316 stainless steel).
Finish: Plain, electro-galvanized or painted.
Service: Designed to be used in conjunction with a base stand to sup- port pipe...
Approvals: There are no approval options for this product.
Ordering: Specify size, figure number and finish. Base stand can be ordered...
Notes: There are no notes for this product.
Pipe Saddle Support with U-Bolt – Fig. 425
Material: Carbon steel, saddle, support and u-bolt. (304 and 316 stainless steel).
Finish: Plain, electro-galvanized or painted.
Service: Designed to be used in conjunction with a base stand to support pipe...
Approvals: Complies with Federal Specification WW-H-171-E (Type# 37), A-A-1192 A...
Ordering: Specify size, figure number and finish. Base stand ordered separately...
Notes: There are no notes for this product.
Adjustable Pipe Saddle Support – Fig. 426
Material: Carbon steel saddle and nipple with special cast iron reducing coupling...
Finish: Plain, electro-galvanized or painted.
Service: Designed to be used in conjunction with a base stand to support horizontal...
Approvals: Complies with Federal Specification WW-H-171-E (Type# 39), A-A-1192 A...
Ordering: Specify size, figure number and finish. Base stand ordered separately...
Notes: Adjustable pipe saddle supports are available in stainless steel.
Adjustable Pipe Saddle Support with U-Bolt – Fig. 427
Material: Carbon steel saddle, nipple and u-bolt with special cast iron reducing...
Finish: Plain, galvanized or painted.
Service: Designed to be used in conjunction with a base stand to sup- port horizontal...
Approvals: There are no approval options for this product.
Ordering: Specify size, figure number and finish. Base stand ordered separately...
Notes: Adjustable pipe saddle supports with u-bolts are available in stainless steel.
Adjustable Pipe Saddle Support, Kit – Fig. 428KT
Material: Ductile iron saddle with carbon steel coupling, carbon steel nipple and base...
Finish: All items listed above are hot-dip galvanized except for stainless steel set screws
Service: Designed to support pipe horizontally. Straight cut pipe thread on nipple...
Approvals: There are no approval options for this product.
Ordering: Specify pipe size and figure number.
Notes: Saddles accommodate ductile iron pipe and IPS. Support requires 2" schedule...
Adjustable Pipe Saddle Support, with U-Bolt, Kit – Fig. 429KT
Material: Ductile iron saddle with carbon steel coupling, carbon steel nipple and base...
Finish: All items listed above are hot-dip galvanized except for stainless steel set screws
Service: Designed to support pipe horizontally. Straight cut pipe thread on nipple...
Approvals: There are no approval options for this product.
Ordering: Specify pipe size and figure number.
Notes: Saddles accommodate ductile iron pipe and IPS. Support requires 2" schedule...
Adjustable Bolt on Flange Support Kit – Fig. 431KT
Material: Hot-Dip Galvanized Carbon Steel Saddle with Threaded Coupling...
Finish: All items listed above are hot-dip galvanized except for stainless steel set screws
Service: Designed to support pipe flange horizontally. Straight cut pipe thread on nipple...
Approvals: There are no approval options for this product.
Ordering: Specify pipe size and figure number.
Notes: Support requires 2" schedule 40 extension pipe to be cut in the field...
